Redundancy module
PM-0648-100-0
Characteristics
Benefits
› High efficiency
› Error message via relay contact and LEDs
› Safe parallel operation to increase power
› Fully compatible with Top and Power Boost for your power supplies
› Active operation for minimal power loss even in the event of a short-circuit on the secondary side
› Decoupling with diodes
› 3 years warranty
| Product | Redundancy module |
| Order number | PM-0648-100-0 |
| Series | PM RE |
Input
| Rated input voltage | 48 Vdc |
| Input voltage range | 33 Vdc to 56 Vdc |
| Rated input current | 10 A |
Output
| Rated output voltage | 48 Vdc |
| Rated Output Current | 10 A |
| Output voltage range | 33 Vdc to 56 Vdc |
| Power boost | 120 A, 25 ms / 40 A, 4 s / 30 A, 8 s |
| Max. voltage drop between input and output | 750 mV |
| Max. power loss | 9.7 W |
| Max. feedback resistance | 60 Vdc |
| Parallel connection possible | Yes |
Signaling
| Signal output | Relay contact |
| Status display | 2 x Green LED |
Environment
| Climate class according to EN 60721 | 3K3 |
| Storage temperature | -40 °C to 85 °C / -40 °F to 185 °F |
| Humidity without condensation | 5 % to 96 % |
| Cooling type | natural convection |
| Required minimum distance (side) | 0 mm |
| Required minimum distance (top/bottom) | 30 mm |
Protection and Safety
| Degree of pollution | 2 |
| Protection class according to EN 61140 | III, without PE connection |
| Safety extra low voltage (SELV/PELV) | EN 61140 |
Size and Weight
| Width | 22 mm / 0.87 in |
| Height | 90 mm / 3.54 in |
| Depth | 94 mm / 3.7 in |
| Weight | 0.42 kg / 0.926 lbs |
| Zulassung Schiff |
DNV-CG-0339 |
