ISOLATING TRANSFORMERS

Isolating transformers with galvanic isolation provide a reliable supply to circuits with the safety measures “protective separation”. The transformers provide double or reinforced isolation between the primary and secondary sides. Any requested network configuration is possible for the secondary side, whether this involves a monitored isolated system or grounded system with fuse elements. The output voltage for the isolating transformers can be between 50 Vac and 1,000 Vac or 120 Vdc and 1,415 Vdc.

OVERVIEW

› Double or reinforced isolation between the primary and secondary sides
› Flexible structure for the secondary side network configuration
› Power output: 50 Vac to 1,000 Vac or 120 Vdc to 1,415 Vdc
› Power output: up to 630,000 kVA, higher power ratings upon request

Christoph Carstens

Christoph Carstens

Product Management Transformers

Product search for all Transformers

PRODUCT SEARCH FOR ISOLATING TRANSFORMERS

276 results
Image of BLOCK Item: USTE 100/2x115
USTE 100/2x115
Control- and isolating transformer • 1ph • 100 VA • IN: 208-600 Vac • OUT: 2 x 115 Vac
Product details
Image of BLOCK Item: USTE 250/2x115
USTE 250/2x115
Control- and isolating transformer • 1ph • 250 VA • IN: 208-600 Vac • OUT: 2 x 115 Vac
Product details
Image of BLOCK Item: USTE 400/2x115
USTE 400/2x115
Control- and isolating transformer • 1ph • 400 VA • IN: 208-600 Vac • OUT: 2 x 115 Vac
Product details
Image of BLOCK Item: UTT1-3,2-23
UTT1-3,2-23
Control- and isolating transformer • 1ph • 3200 VA • IN: 208-600 Vac • OUT: 2 x 115 Vac
Product details
Image of BLOCK Item: USTE 630/2x115
USTE 630/2x115
Control- and isolating transformer • 1ph • 630 VA • IN: 208-600 Vac • OUT: 2 x 115 Vac
Product details
Image of BLOCK Item: UTT1-4-23
UTT1-4-23
Control- and isolating transformer • 1ph • 4000 VA • IN: 208-600 Vac • OUT:  115-230 Vac
Product details
Image of BLOCK Item: UTT1-6-23
UTT1-6-23
Control- and isolating transformer • 1ph • 6000 VA • IN: 208-600 Vac • OUT:  115-230 Vac
Product details
Image of BLOCK Item: USTE 800/2x115
USTE 800/2x115
Control- and isolating transformer • 1ph • 800 VA • IN: 208-600 Vac • OUT: 2 x 115 Vac
Product details
Image of BLOCK Item: USTE 1000/2x115
USTE 1000/2x115
Control- and isolating transformer • 1ph • 1000 VA • IN: 208-600 Vac • OUT: 2 x 115 Vac
Product details
Image of BLOCK Item: USTE 1200/2x115
USTE 1200/2x115
Control- and isolating transformer • 1ph • 1200 VA • IN: 208-600 Vac • OUT: 2 x 115 Vac
Product details
Image of BLOCK Item: USTE 1600/2x115
USTE 1600/2x115
Control- and isolating transformer • 1ph • 1600 VA • IN: 208-600 Vac • OUT: 2 x 115 Vac
Product details
Image of BLOCK Item: USTE 2500/2x115
USTE 2500/2x115
Control- and isolating transformer • 1ph • 2500 VA • IN: 208-600 Vac • OUT: 2 x 115 Vac
Product details
