Switched mode power supplies

BLOCK customers benefit from an extensive standard range of switched mode power supplies for the reliable supply of machines and systems. The Power Compact, Power Mini, Power Vision, and Power Eco Line product lines provide both basic functions as well as comprehensive communications and optimum technical functionality.  Make the most of the efficient, compact and robust features of the Power Mini and Power Compact series. Geared towards meeting high standards, the powerful switched-mode power supplies in the Power Vision series provide maximum power reserves and extensive configuration and monitoring options. Power Eco Line switched mode power supplies are suitable for single-phase use in small control systems.

Overview:

◼︎  Input voltage: 100 Vac to 500 Vac; 48 Vdc to 94 Vdc
◼︎  Output voltage: 5 Vdc to 60 Vdc
◼︎  Stabilized or adjustable output voltage
◼︎  Output current: 0,17 to 40 A
◼︎  Top Boost and Power Boost
◼︎  ePlan

Your contact:

Sebastian Winter

Sebastian WinterProduct Manager Electronics

Downloads

Power Compact Champ – our new single-phase power supplies

Maximum system availability, strong and flexible in any application, yet efficient and compact - the new power supplies of the Power Compact Champ (PCC) series. PCC combines all the features to meet the requirements of a wide range of applications and industries - a compact design with above-average electrical and mechanical robustness at the same time.

Find out more

Product search for all Power supplies / Circuit breakers

Product search for Switched ­mode power supplies

View filter
Phases
Input voltage
Output voltage
Approvals
Output current
70 Versions of 17 products
Or do you have different requirements? We can help you!
Image of BLOCK Item: PEL 230
PEL 230
Single-phase, primary switched mode power supply
PRI 100 – 240 Vac, SEC 5 – 24 Vdc, 1.1 – 6.5 A, Stabilized and adjustable output voltage
Display options
Version Input rated voltage Output rated voltage Output rated current
PEL 230/5-5,5 100 - 240 Vac 5 Vdc 5.5 A
PEL 230/12-2 100 - 240 Vac 12 Vdc 2 A
PEL 230/12-4 100 - 240 Vac 12 Vdc 4 A
PEL 230/12-6,5 100 - 240 Vac 12 Vdc 6.5 A
PEL 230/18-1,1 100 - 240 Vac 18 Vdc 1.1 A
PEL 230/18-2,5 100 - 240 Vac 18 Vdc 2.5 A
PEL 230/24-1,3 100 - 240 Vac 24 Vdc 1.3 A
PEL 230/24-2,5 100 - 240 Vac 24 Vdc 2.5 A
PEL 230/24-4 100 - 240 Vac 24 Vdc 4 A
Or do you have different requirements? We can help you!
Image of BLOCK Item: PM 1AC
PM 1AC
Single-phase, primary switched mode power supply
PRI 100 – 240 Vac, SEC 12 – 48 Vdc, 2 – 7 A, Low stand-by consumption <1 W
Display options
Version Input rated voltage Output rated voltage Output rated current Characteristics
PM-0112-020-0 100 - 240 Vac 12 Vdc 2 A / NEC Class 2 For establishing NEC Class 2 circuits
PM-0112-040-0 100 - 240 Vac 12 Vdc 4 A / NEC Class 2 For establishing NEC Class 2 circuits
PM-0112-070-0 100 - 240 Vac 12 Vdc 7 A -
PM-0124-010-0 100 - 240 Vac 24 Vdc 1 A / NEC Class 2 For establishing NEC Class 2 circuits
PM-0124-020-0 100 - 240 Vac 24 Vdc 2 A / NEC Class 2 For establishing NEC Class 2 circuits
PM-0124-020-4 100 - 240 Vac 24 Vdc 2 A Suitable for the medical field
PM-0124-038-0 100 - 240 Vac 24 Vdc 3.8 A / NEC Class 2 For establishing NEC Class 2 circuits
PM-0124-040-0 100 - 240 Vac 24 Vdc 4 A -
PM-0130-030-0 100 - 240 Vac 30.5 Vdc 3 A
PM-0148-020-0 100 - 240 Vac 48 Vdc 2 A -
Or do you have different requirements? We can help you!
Image of BLOCK Item: PCC 1AC
PCC 1AC
Single-phase, primary switched mode power supply
PRI 100 – 240 Vac, SEC 24 Vdc, 5 – 40 A
Display options
Version Input rated voltage Output rated voltage Output rated current Characteristics
PCC-0124-050-2 100 - 240 Vac 24 Vdc 5 A Power Boost
PCC-0124-100-2 100 - 240 Vac 24 Vdc 10 A Power Boost
PCC-0124-200-2 100 - 240 Vac 24 Vdc 20 A Power Boost
PCC-0124-400-2 100 - 240 Vac 24 Vdc 40 A Power Boost
Or do you have different requirements? We can help you!
Image of BLOCK Item: PC 1AC
PC 1AC
Single-phase, primary switched mode power supply
PRI 100 – 240 Vac, SEC 12 – 48 Vdc, 5 – 20 A, Fast tripping of conventional circuit breakers
Display options
Version Input rated voltage Output rated voltage Output rated current Characteristics
PC-0112-150-0 100 - 240 Vac 12 Vdc 15 A Active inrush current limit
PC-0124-050-0 100 - 240 Vac 24 Vdc 5 A -
PC-0124-050-4 100 - 240 Vac 24 Vdc 5 A Suitable for the medical field
PC-0124-100-0 100 - 240 Vac 24 Vdc 10 A Active inrush current limit
PC-0124-100-4 100 - 240 Vac 24 Vdc 10 A Suitable for the medical field
PC-0124-200-0 100 - 240 Vac 24 Vdc 20 A Active inrush current limit
PC-0148-050-0 100 - 240 Vac 48 Vdc 5 A Active inrush current limit
PC-0148-100-0 100 - 240 Vac 48 Vdc 10 A Active inrush current limit
Or do you have different requirements? We can help you!
Image of BLOCK Item: PVSE 230
PVSE 230
Single-phase, primary switched mode power supply, Economy
PRI 100 – 240 Vac, SEC 12 – 48 Vdc, 3 – 20 A, Stand-by-input
Display options
Version Input rated voltage Output rated voltage Output rated current
PVSE 230/12-6 100 - 240 Vac 12 Vdc 6 A
PVSE 230/12-15 100 - 240 Vac 12 Vdc 15 A
PVSE 230/24-5 100 - 240 Vac 24 Vdc 5 A
PVSE 230/24-10 110 - 240 Vac 24 Vdc 10 A
PVSE 230/24-20 110 - 240 Vac 24 Vdc 20 A
PVSE 230/48-5 110 - 240 Vac 48 Vdc 5 A
PVSE 230/48-10 110 - 240 Vac 48 Vdc 10 A
Or do you have different requirements? We can help you!
Image of BLOCK Item: PM 2AC
PM 2AC
Two-phase, primary switched mode power supply
PRI 200 – 500 Vac, SEC 24 Vdc, 3.8 A, Constant current limiting without overload shutdown
Display options
Version Input rated voltage Output rated voltage Output rated current Characteristics
PM-0224-038-0 200 - 500 Vac 24 Vdc 3.8 A For establishing NEC Class 2 circuits
Or do you have different requirements? We can help you!
Image of BLOCK Item: PC 2AC
PC 2AC
Single- and two-phase, primary switched mode power supply
PRI 200 – 500 Vac, SEC 24 Vdc, 5 – 10 A, Fast tripping of conventional circuit breakers
Display options
Version Input rated voltage Output rated voltage Output rated current Characteristics
PC-0224-050-0 200 - 500 Vac 24 Vdc 5 A -
PC-0224-050-2 200 - 500 Vac 24 Vdc 5 A Power Boost
PC-0224-100-0 200 - 500 Vac 24 Vdc 10 A -
PC-0224-100-2 200 - 500 Vac 24 Vdc 10 A Power Boost
Or do you have different requirements? We can help you!
Image of BLOCK Item: PC 3AC
PC 3AC
Three-phase primary switched mode power supply
PRI 400 – 500 Vac, SEC 24 – 60 Vdc, 10 – 40 A, Fast tripping of conventional circuit breakers
Display options
Version Input rated voltage Output rated voltage Output rated current Characteristics
PC-0324-100-0 400 - 500 Vac 24 Vdc 10 A -
PC-0324-100-2 400 - 500 Vac 24 Vdc 10 A Power Boost
PC-0324-200-0 400 - 500 Vac 24 Vdc 20 A -
PC-0324-200-2 400 - 500 Vac 24 Vdc 20 A Power Boost
PC-0324-400-0 400 - 500 Vac 24 Vdc 40 A -
PC-0324-400-2 400 - 500 Vac 24 Vdc 40 A Power Boost
PC-0348-200-0 400 - 500 Vac 48 Vdc 20 A -
PC-0348-200-2 400 - 500 Vac 48 Vdc 20 A Power Boost
PC-0360-160-2 400 - 500 Vac 60 Vdc 16 A Power Boost
Or do you have different requirements? We can help you!
Image of BLOCK Item: PVSE 400
PVSE 400
Three-phase, primary switched mode power supply, Economy
PRI 400 – 500 Vac, SEC 24 – 48 Vdc, 10 – 40 A, Stabilized and adjustable output voltage
Display options
Version Input rated voltage Output rated voltage Output rated current
PVSE 400/24-10 3 x 400 - 500 Vac 24 Vdc 10 A
PVSE 400/24-20 3 x 400 - 500 Vac 24 Vdc 20 A
PVSE 400/24-40 3 x 400 - 500 Vac 24 Vdc 40 A
PVSE 400/30-25 3 x 400 - 500 Vac 30 Vdc 25 A
PVSE 400/48-10 3 x 400 - 500 Vac 48 Vdc 10 A
PVSE 400/48-20 3 x 400 - 500 Vac 48 Vdc 20 A
Or do you have different requirements? We can help you!
Image of BLOCK Item: PVSB 400
PVSB 400
Three-phase, primary switched mode power supply, Basic
PRI 400 – 500 Vac, SEC 24 Vdc, 10 – 40 A, RS-232 interface
Display options
Version Input rated voltage Output rated voltage Output rated current
PVSB 400/24-10 3 x 400 - 500 Vac 24 Vdc 10 A
PVSB 400/24-20 3 x 400 - 500 Vac 24 Vdc 20 A
PVSB 400/24-40 3 x 400 - 500 Vac 24 Vdc 40 A
Or do you have different requirements? We can help you!
