Battery module
PBAT-1224-130-0 - Discontinued items – not for new applications
Characteristics
Benefits
› Automatic detection of battery modules at UPS control unit
› Reliable early warning signal when battery life expectancy is declining
› Extended life expectancy through temperature controlled battery management
› Service-friendly spring-loaded connector system
Input
| Rated input voltage | 24 Vdc |
| Input voltage range | 24 Vdc |
Output
| Rated output voltage | 24 Vdc |
| Rated Output Current | 40 A |
| Output voltage range | 24 Vdc |
General
| Type of energy storage | Battery |
| Mounting position | nicht über Kopf, Direktverschraubung |
| Max. Charging Current | 5 A |
| Self discharge | 1,5% / Monat bei 20°C |
Environment
| Storage temperature | -40 °C to 60 °C / -40 °F to 140 °F |
| Ambient temperature | -40 °C to 60 °C / -40 °F to 140 °F |
| Degree of pollution | 2 |
Safety and protection
| Protection class according to EN 61140 | III |
| Recommended end-of-charge voltage (at 25°C) | 27 Vdc |
| End-of-Charge Voltage | 27 Vdc |
| Protection type | IP20 |
General
| Mounting position | nicht über Kopf, Direktverschraubung |
| Weight | 12.3 kg / 27.117 lbs |
