Buffer module
PVUC 24/24-10
Characteristics
Benefits
› Electronic overcurrent and short-circuit protection
› Reverse polarity protection
› Configurable switch-in threshold
› 3 LEDs for signalling purposes
› Isolated signal contact
› Service-friendly spring-loaded connector system
› Parallel connection option
› Decoupled output
› Panel installation on mounting rails
| Product | Buffer module |
| Order number | PVUC 24/24-10 |
| Series | BUFFER MODULES |
Input
| Rated input voltage | 24 Vdc |
| Input voltage range | 20 Vdc to 30 Vdc |
Output
| Rated output voltage | 24 Vdc |
| Rated Output Current | 10 A |
| Output voltage range | 20 Vdc to 24 Vdc |
| Max. feedback resistance | 35 Vdc |
| Parallel connection possible | Yes |
| Series connection possible | No |
Signaling
| Signal output | Relay contact |
| Status display | Green, yellow, red LED |
Environment
| Ambient temperature | -10 °C to 50 °C / 14 °F to 122 °F |
| Storage temperature | -10 °C to 60 °C / 14 °F to 140 °F |
| Humidity without condensation | 5 % to 96 % |
| Cooling type | natural convection |
Size and Weight
| Width | 57 mm / 2.24 in |
| Height | 127 mm / 5 in |
| Depth | 179.6 mm / 7.07 in |
| Weight | 1.2 kg / 2.646 lbs |
| cULus | UL 508 - Listed |
