Communication module
EB-MODBUS-RTU
Characteristics
Benefits
› Communication interface between BUS module and EasyB modules
› Up to 31 units with a total of 40 channels per unit
› All functions of the circuit breaker (communication, characteristics) can continue to be used.
› Automatic viation of all signals by right-hand alignment
| Product (Headline_Detailseite) | Communication module |
| Order number (PF_Teilenummer) | EB-MODBUS-RTU |
| Series (PF_Baureihe) | EB-ACCESSORIE |
Output
| Idle current @ 24 V (EWS_Ruhestrom_im_Leerlauf) | 26 mA |
| Max. feedback resistance (EWS_Rueckspeisefestigkeit_max) | 35 Vdc |
| Power losses in stand-by mode (EWS_Verlustleistung_im_Leerlauf_24_V) | 0.40 W |
Signaling
| Potential-free signal output (PIM_alt_potenzialfreier_signalausgang_2) | 24" Solid State Relay 58 Vdc/ 40 Vac/ 100 mA |
| Potential-free signal output (PIM_alt_potenzialfreier_signalausgang_1) | 14" Solid State Relay 58 Vdc/ 40 Vac/ 100 mA |
| Signal input (ON/OFF/Reset) (PIM_alt_signaleingang) | Reset input Level high = min. 11 Vdc, max. 30 Vdc Level low = min. 0 Vdc, max. 5 Vdc Jitter: +/- 5 %; +/- 5 ms |
Environment
| Climate class according to EN 60721 (EWS_Klimaklasse) | 3K3 |
| Ambient temperature (PF_Umgebungstemperatur) | -25 °C to 70 °C / -13 °F to 158 °F |
| Storage temperature (PF_Lagertemperatur) | -25 °C to 85 °C / -13 °F to 185 °F |
| Humidity without condensation (EWS_Luftfeuchtigkeit) | 5 % to 96 % |
| Cooling type (PF_Kuehlungsart) | natural convection |
| Required minimum distance (side) (EWS_Erforderlicher_Mindestabstand) | 0 mm |
| Required minimum distance (top/bottom) (EWS_Erforderlicher_Mindestabstand_oben_unten) | 30 mm |
Protection and Safety
| Degree of pollution (EWS_Verschmutzungsgrad) | 2 |
Size and Weight
| Width (PF_Breite_mm) | 12 mm / 0.47 in |
| Height (PF_Hoehe_mm) | 99 mm / 3.9 in |
| Depth (PF_Tiefe_mm) | 60 mm / 2.36 in |
| Weight (PF_Gewicht_kg) | 0.04 kg / 0.088 lbs |
| cULus | UL 508 - Listed |
