BLOCK customers benefit from an extensive standard range of switched mode power supplies for the reliable supply of machines and systems. The Power Compact, Power Mini, Power Vision, and Power Eco Line product lines provide both basic functions as well as comprehensive communications and optimum technical functionality. Make the most of the efficient, compact and robust features of the Power Mini and Power Compact series. Geared towards meeting high standards, the powerful switched-mode power supplies in the Power Vision series provide maximum power reserves and extensive configuration and monitoring options. Power Eco Line switched mode power supplies are suitable for single-phase use in small control systems.
Product search for Switched mode power supplies
Phases
Input voltage
Output voltage
Approvals
- AS-interface (1)
- DNV GL (13)
- Germanischer Lloyd (22)
- NEC Class 2 (6)
- UL 60601-1 (3rd ed. 2MOPP) (4)
- UL/CSA 508 listed (65)
- UL/CSA 508 listed (pending) (1)
- UL/CSA 60950-1 recognised (E213214) (65)
- UL/CSA 60950-1 recognised (pending) (1)
- in preparation (1)
Output current
72 Versions of 17 products
Or do you have different requirements?
We can help you!
PEL 230
Single-phase, primary switched mode power supply
PRI 100 – 240 Vac, SEC 5 – 24 Vdc, 1.1 – 6.5 A, Stabilised and adjustable output voltage
| Version | Input rated voltage | Output rated voltage | Output rated current |
|---|---|---|---|
| PEL 230/5-5,5 | 100 - 240 Vac | 5 Vdc | 5.50 A |
| PEL 230/12-2 | 100 - 240 Vac | 12 Vdc | 2.00 A |
| PEL 230/12-4 | 100 - 240 Vac | 12 Vdc | 4.00 A |
| PEL 230/12-6,5 | 100 - 240 Vac | 12 Vdc | 6.50 A |
| PEL 230/18-1,1 | 100 - 240 Vac | 18 Vdc | 1.10 A |
| PEL 230/18-2,5 | 100 - 240 Vac | 18 Vdc | 2.50 A |
Or do you have different requirements?
We can help you!
PEL Neo
Single-phase, primary switched mode power supply
PRI 100 – 240 Vac, SEC 24 Vdc, 1.3 – 4 A, Stabilised and adjustable output voltage
| Version | Input rated voltage | Output rated voltage | Output rated current |
|---|---|---|---|
| PEL-0124-013-0 | 100 - 240 Vac | 24 Vdc | 1.30 A |
| PEL-0124-025-0 | 100 - 240 Vac | 24 Vdc | 2.50 A |
| PEL-0124-040-0 | 100 - 240 Vac | 24 Vdc | 4.00 A |
Or do you have different requirements?
We can help you!
PM 1AC
Single-phase, primary switched mode power supply
PRI 100 – 240 Vac, SEC 12 – 48 Vdc, 2 – 7 A, Low stand-by consumption <1 W
| Version | Input rated voltage | Output rated voltage | Output rated current | Characteristics |
|---|---|---|---|---|
| PM-0112-020-0 | 100 - 240 Vac | 12 Vdc | 2 A / NEC Class 2 | For establishing NEC Class 2 circuits |
| PM-0112-040-0 | 100 - 240 Vac | 12 Vdc | 4 A / NEC Class 2 | For establishing NEC Class 2 circuits |
| PM-0112-070-0 | 100 - 240 Vac | 12 Vdc | 7 A | - |
| PM-0124-010-0 | 100 - 240 Vac | 24 Vdc | 1 A / NEC Class 2 | For establishing NEC Class 2 circuits |
| PM-0124-020-0 | 100 - 240 Vac | 24 Vdc | 2 A / NEC Class 2 | For establishing NEC Class 2 circuits |
| PM-0124-020-4 | 100 - 240 Vac | 24 Vdc | 2 A | Suitable for the medical field |
| PM-0124-038-0 | 100 - 240 Vac | 24 Vdc | 3.8 A / NEC Class 2 | For establishing NEC Class 2 circuits |
| PM-0124-040-0 | 100 - 240 Vac | 24 Vdc | 4 A | - |
| PM-0130-030-0 | 100 - 240 Vac | 30,5 Vdc | 3 A / Compatible to AS-i | Compatible to AS-i |
| PM-0148-020-0 | 100 - 240 Vac | 48 Vdc | 2 A | - |
Or do you have different requirements?
We can help you!
PC 1AC
Single-phase, primary switched mode power supply
PRI 100 – 240 Vac, SEC 12 – 48 Vdc, 5 – 20 A, Fast tripping of conventional circuit breakers
| Version | Input rated voltage | Output rated voltage | Output rated current | Characteristics |
|---|---|---|---|---|
| PC-0112-150-0 | 100 - 240 Vac | 12 Vdc | 15 A | Active inrush current limit |
| PC-0124-050-0 | 100 - 240 Vac | 24 Vdc | 5 A | - |
| PC-0124-050-4 | 100 - 240 Vac | 24 Vdc | 5 A | Suitable for the medical field |
| PC-0124-100-0 | 100 - 240 Vac | 24 Vdc | 10 A | Active inrush current limit |
| PC-0124-100-4 | 100 - 240 Vac | 24 Vdc | 10 A | Suitable for the medical field |
| PC-0124-200-0 | 100 - 240 Vac | 24 Vdc | 20 A | Active inrush current limit |
| PC-0124-200-4 | 100 - 240 Vac | 24 Vdc | 20 A | Suitable for the medical field |
| PC-0148-050-0 | 100 - 240 Vac | 48 Vdc | 5 A | Active inrush current limit |
| PC-0148-100-0 | 100 - 240 Vac | 48 Vdc | 10 A | Active inrush current limit |
Or do you have different requirements?
We can help you!
PVSE 230
Single-phase, primary switched mode power supply, Economy
PRI 100 – 240 Vac, SEC 12 – 48 Vdc, 3 – 20 A, Stand-by-input
| Version | Input rated voltage | Output rated voltage | Output rated current | Characteristics |
|---|---|---|---|---|
| PVSE 230/12-6 | 100 - 240 Vac | 12 Vdc | 6.00 A | - |
| PVSE 230/12-10 | 100 - 240 Vac | 12 Vdc | 10.00 A | - |
| PVSE 230/12-15 | 100 - 240 Vac | 12 Vdc | 15.00 A | Active inrush current limit |
| PVSE 230/24-3 | 100 - 240 Vac | 24 Vdc | 3.00 A | - |
| PVSE 230/24-3B | 100 - 240 Vac | 24 Vdc | 3.00 A | Active inrush current limit |
| PVSE 230/24-5 | 100 - 240 Vac | 24 Vdc | 5.00 A | - |
| PVSE 230/24-5B | 100 - 240 Vac | 24 Vdc | 5.00 A | - |
| PVSE 230/24-10 | 110 - 240 Vac | 24 Vdc | 10.00 A | Active inrush current limit |
| PVSE 230/24-20 | 110 - 240 Vac | 24 Vdc | 20.00 A | Active inrush current limit |
| PVSE 230/30-15 | 110 - 240 Vac | 30 Vdc | 15.00 A | Active inrush current limit |
| PVSE 230/48-5 | 110 - 240 Vac | 48 Vdc | 5.00 A | Active inrush current limit |
| PVSE 230/48-10 | 110 - 240 Vac | 48 Vdc | 10.00 A | Active inrush current limit |
Or do you have different requirements?
We can help you!
PM 2AC
Two-phase, primary switched mode power supply
PRI 200 – 500 Vac, SEC 24 Vdc, 3.8 A, Constant current limiting without overload shutdown
| Version | Input rated voltage | Output rated voltage | Output rated current | Characteristics |
|---|---|---|---|---|
| PM-0224-038-0 | 200 - 500 Vac | 24 Vdc | 3.8 A | For establishing NEC Class 2 circuits |
Or do you have different requirements?
We can help you!
PC 2AC
Single- and two-phase, primary switched mode power supply
PRI 200 – 500 Vac, SEC 24 Vdc, 5 – 10 A, Fast tripping of conventional circuit breakers
| Version | Input rated voltage | Output rated voltage | Output rated current | Characteristics |
|---|---|---|---|---|
| PC-0224-050-0 | 200 - 500 Vac | 24 Vdc | 5 A | - |
| PC-0224-050-2 | 200 - 500 Vac | 24 Vdc | 5 A | Power Boost |
| PC-0224-100-0 | 200 - 500 Vac | 24 Vdc | 10 A | - |
| PC-0224-100-2 | 200 - 500 Vac | 24 Vdc | 10 A | Power Boost |
Or do you have different requirements?
We can help you!
PC 3AC
Three-phase, primary switched mode power supply
PRI 400 – 500 Vac, SEC 24 – 60 Vdc, 10 – 40 A, Fast tripping of conventional circuit breakers
| Version | Input rated voltage | Output rated voltage | Output rated current | Characteristics |
|---|---|---|---|---|
| PC-0324-100-0 | 400 - 500 Vac | 24 Vdc | 10 A | - |
| PC-0324-100-2 | 400 - 500 Vac | 24 Vdc | 10 A | Power Boost |
| PC-0324-200-0 | 400 - 500 Vac | 24 Vdc | 20 A | - |
| PC-0324-200-2 | 400 - 500 Vac | 24 Vdc | 20 A | Power Boost |
| PC-0324-400-0 | 400 - 500 Vac | 24 Vdc | 40 A | - |
| PC-0324-400-2 | 400 - 500 Vac | 24 Vdc | 40 A | Power Boost |
| PC-0348-200-0 | 400 - 500 Vac | 48 Vdc | 20 A | - |
| PC-0348-200-2 | 400 - 500 Vac | 48 Vdc | 20 A | Power Boost |
| PC-0360-160-2 | 400 - 500 Vac | 60 Vdc | 16 A | - |
Or do you have different requirements?
We can help you!
PVSE 400
Three-phase, primary switched mode power supply, Economy
PRI 400 – 500 Vac, SEC 24 – 48 Vdc, 10 – 40 A, Stabilised and adjustable output voltage
| Version | Input rated voltage | Output rated voltage | Output rated current |
|---|---|---|---|
| PVSE 400/24-10 | 3 x 400 - 500 Vac | 24 Vdc | 10.00 A |
| PVSE 400/24-20 | 3 x 400 - 500 Vac | 24 Vdc | 20.00 A |
| PVSE 400/24-40 | 3 x 400 - 500 Vac | 24 Vdc | 40.00 A |
| PVSE 400/30-25 | 3 x 400 - 500 Vac | 30 Vdc | 25.00 A |
| PVSE 400/48-10 | 3 x 400 - 500 Vac | 48 Vdc | 10.00 A |
| PVSE 400/48-20 | 3 x 400 - 500 Vac | 48 Vdc | 20.00 A |
Or do you have different requirements?
We can help you!
PVSB 400
Three-phase, primary switched mode power supply, Basic
PRI 400 – 500 Vac, SEC 24 Vdc, 10 – 40 A, RS-232 interface
| Version | Input rated voltage | Output rated voltage | Output rated current |
|---|---|---|---|
| PVSB 400/24-10 | 3 x 400 - 500 Vac | 24 Vdc | 10.00 A |
| PVSB 400/24-20 | 3 x 400 - 500 Vac | 24 Vdc | 20.00 A |
| PVSB 400/24-40 | 3 x 400 - 500 Vac | 24 Vdc | 40.00 A |
Or do you have different requirements?
We can help you!
Results 1 - 10 of 17
