EB-2724-2080-0
2-Channel circuit breaker, EasyB
Input rated voltage
24 Vdc
Output rated current
2 x 4 A
| Version | Input rated voltage | Output rated current | ||
|---|---|---|---|---|
| EB-2724-2020-0 | 24 Vdc | 2 x 1 A | ||
| EB-2724-2040-0 | 24 Vdc | 2 x 2 A | ||
| EB-2724-2060-0 | 24 Vdc | 2 x 3 A | ||
| EB-2724-2080-0 | 24 Vdc | 2 x 4 A | ||
| EB-2724-2120-0 | 24 Vdc | 2 x 6 A | ||
| EB-2724-2160-0 | 24 Vdc | 2 x 8 A |
DOWNLOADS
Technical files
Manual
Instruction manual
Dimension sheet
Approvals / Manufacturer's declaration
UL 508 Listed USA (E219022)
UL 508 Listed Canada (E219022)
COC UL 508 & CSA 22.2
UL 2367 USA (E356250)
COA UL 2367 & CSA 22.2
COC UL 2367 & CSA 22.2
EAC approval
Marine DNV GL (TAA000022T)
EU-Declaration of Conformity
CAD/CAE data
ePlan Macro
3D-CAD-Model (STEP)
Additional information
Brochure EasyB
eBreaker brochure
Technical data for EB-2724-2080-0
| Input | |
|---|---|
| Input rated voltage | 24 Vdc |
| Input voltage range | 18 - 30 Vdc |
| Maximal residual ripple of supplied input voltage | 3 % |
| Max. total input current | 8 A |
| Max. input current for each pole of terminal | 10 A (-), 40 A (+) |
| Required input voltage for turning-on of outputs | 17.5 V (Turn-off Threshold 16.7 V), ± 0.7 V |
| Max. power losses | 0,4 W |
| Over voltage protection | Suppressor diode 33 V |
| Stand-by current | 12 mA @ 24 V |
| Power losses in stand-by mode | 0,3 W @ 24 V |
| Turn on capacity | 80 mF @ 24 Vdc / 2,5 mm² / 2,5 m |
| Output | |
|---|---|
| Output rated voltage | 24 Vdc |
| Output rated current | 2 x 4 A |
| Maximum voltage drop between input and output | 34 mV |
| Initialization time of module | 27 ms |
| Turn-on delay of outputs | 0 ms |
| Waiting periode after switch-off of an output | 500 ms (Short circuit) … 5 s (Overload) |
| Maximum turn-on capacity for each channel | 60 mF |
| Parallel use of outputs | Not allowed |
| Serial use of outputs | not allowed |
| Resistance to reverse feed max. | 35 Vdc |
| Efficiency | 99.0 % |
| Signaling | |
|---|---|
| Bus communication | Collective notification signal |
| Status indicator | LED (red, green, orange) |
| Signal output | Output status, short circuit proof high = Channel on, low = Channel off, fault |
| Approvals | |
|---|---|
| Approvals | cURus, cULus, DNV GL |
| Environment | |
|---|---|
| Type of cooling | Natural convection |
| Ambient temperature | -25 °C … +70 °C |
| Storage temperature | -25 °C … +85 °C |
| Relative humidity | 5 … 96 %, without condensation |
| Required minimum spacing (left/right) | 0 mm |
| Required minimum spacing (over/under) | 30 mm |
| Safety and protection | |
|---|---|
| Protection index | IP 20 |
| Safety class | III, without PE connection |
| Degree of pollution | 2 |
| Terminal and mounting | |
|---|---|
| Terminals input, (spring clamp terminal) | max. 16 mm² |
| Terminals output, (spring clamp terminal) | max 2,5 mm² (2 x "+") |
| Terminals signalling, (spring clamp terminal) | max. 2,5 mm² |
| Mounting position | horizontal for standard rail DIN TS35 |
| Measures and weights | |
|---|---|
| Width | 12 mm |
| Height | 99 mm |
| Depth | 60 mm |
| Weight | 0.039 kg |
Info on EasyB 2-Channel thermomagnetic series
General Data
- Efficiency up to 99 %
- Up to 40 fuse channels stackable side by side
- With thermomagnetic characteristic
- Multi-coloured LED and status display button
- Ambient temperature -25 °C … +55 °C / +70 °C
- Protection index IP 20
Benefits
- Compact design - 2 independent channels in 12 mm width
- Automatic channel assignment
- Additional load outputs through output expanders mountable side by side
- 3 years warranty
